With the development of the fully hydraulic
CR 10 soil compactor, Weber MT has produced a new, powerful machine in "large format": a centrifugal force of 100 kN, a 3-cylinder water-cooled diesel engine and an operating weight of 900 kg.
Some good reasons for the CR 10:
- Water-cooled 3-cylinder diesel engine - ample power reserve.
- Starter module with hourmeter, indicators and engine protection functions for oil pressure, battery voltage, engine temperature and air filter restrictor.
- Frequency adjustment.
- Infinitely variable hydraulic control of
forward and reverse travel by means of a finger-tip switch.
- Closed engine hood and "vandalism protection".
- Handlebar adjustable in height.
- Tie-down lugs and folding lifting lug.
Available extras:
Extension plates.
Type |
CR 10 |
Operating weight according to CECE, including standard extension plates |
900 kg |
Centrifugal force |
100 kN |
Frequency |
52 Hz (3120 rpm) |
Drive |
Hydraulic |
Working width |
700*/800/950** mm |
Engine manufacturer |
Lombardini – Diesel |
Type of engine |
LDW 1003 (water – cooler) |
Max. output, DIN 70020 |
19.5 kW (26.5 HP) |
Working speed |
0-27 m/min |
Gradeability (depending on soil condition) |
30% |
