Type |
CF 3 R |
CF 3 HD |
CF 3 |
|
Operating weight CECE |
99 kg |
99 kg |
113 kg |
|
Centrifugal force |
20 kN |
20 kN |
20 kN |
|
Frequency |
95 Hz (5700 rpm) |
95 Hz (5700 rpm) |
95 Hz (5700 rpm) |
|
Operating width |
500 mm |
500 mm |
500 mm |
|
Engine manufacturer |
Robin EX 17 |
Honda GX 160 |
Lombardini 15 LD 225 |
|
Engine type |
4 – stroke, gasoline |
4 – stroke, gasoline |
Diesel |
|
Engine power output, max |
4.2 kW (5.7 HP) |
3.6 kW (4.9 HP) |
3.5 kW (4.8 HP) |
|
Power output at operating speed |
2.8 kW (3.8 HP) at 3000 rpm |
2.7 kW (3.7 HP) at 3000 rpm |
3.1 kW (4.2 HP) at 3000 rpm |
|
Working speed |
26 m/min |
26 m/min |
26 m/min |
